How to Compare PEV Batteries

EZbike Canada|Best Aventon Ebike Canada

Voltage

Best Aventon Ebike Canada

Most modern PEVs, and 100% of what we sell here at EZ Bike, are powered by lithium-ion battery cells. Each of them is 4.2V when fully charged and 2.5V when fully drained. However, since batteries can be damaged when fully drained, systems are put in place to cut off power when the voltage reaches a certain threshold, usually around 3.0V. Because a cell’s voltage fluctuates between 4.2V and 3.0V during use, some companies advertise values calculated using mid-point values of around 3.6V to 3.7V, while others use the fully charged voltage of 4.2V. There is no right or wrong, and no one way is preferable over the other, but problems arise when you try to make comparisons on specs that don’t describe the same things.

Here’s a chart of all the commonly used battery voltages, so you can easily compare them side by side:

Nominal Voltage

S-Group Size

Fully Charged

Cut-Off

Mid-Point Voltage

Nominal is Based On

Examples

36V

10

42V

30V

36V - 37V

Mid-Point

Ninebot Max, Aventon Soltera, Xiaomi M365

48V

13

54.6V

39V

46.8V - 48.1V

Mid-Point

Most Aventon e-bikes, VSETT 8/9, Teverun Blade Mini

52V

14

58.8V

42V

50.4V - 51.8V

Mid-Point

Dualtron Mini, Dualtron Popular, Segway GT series, Apollo Pro

60V

16

67.2V

48V

57.6V - 59.2V

Mid-Point

Dualtron Victor series, VSETT 10+, Kaabo Mantis series

72V

20

84V

60V

72V - 74V

Mid-Point

Dualtron Thunder & Ultra II, Kaabo Wolf King GT Pro, Nami Burn-e

84V

23

96.6V

69V

82.8V - 85.1V

Mid-Point

Dualtron Storm Limited, Dualtron X-Limited

100.8V

24

100.8V

72V

86.4V - 88.8V

Fully Charged

Veteran Sherman, Begode EXN, Inmotion V12, Kingsong S19

126V

30

126V

90V

108V - 111V

Fully Charged

Veteran Patton, Inmotion V13, Kingsong S22

134.4V

32

134.4V

96V

115.2V - 118.4V

Fully Charged

Begode Master, Begode EX30, Extreme Bull Commander Pro



By the way, your device’s charger will always have the fully charged voltage printed or stickered on it.

Power Output

 Power passes from your battery to your controller and then to your motor. Generally speaking, motors are not the bottleneck, as they merely allow electrons to pass through copper coils and spin. However, either your battery or controller can be the limiting factor. In this article, we will focus on the battery, and power is measured in watts.

Level.2 Commuter Ebike Step-over

 Many people think that higher voltage equates to more power or more speed. This is true, but not entirely accurate, since wattage is calculated by multiplying voltage by amperage. Many batteries label their maximum output in amps.

Capacity

 The unit for capacity is watt hours or Wh.  It is a battery’s voltage multiplied by its amp hour rating, or Ah.  Just remember, when comparing PEVs of different voltages or different makes, make sure you use the same measurements, as mentioned above, not always the advertised voltage.  Meaning either fully charged voltage or midpoint, but don’t mix and match them and stay consistent.  For example, a Nami Burn-e 2 Max advertises 40Ah capacity at 72V so 2880Wh, and an Inmotion V13 advertises 24Ah capacity at 126V 3024Wh.  So does the Burn-e have 95% the battery capacity of the V13?  No, because we just mixed fully charged and mid-point voltages.  Let’s re-do the math using all mid-point voltage values of 3.6V.  This would give 40 x 72 = 2880Wh for the Burn-e, and 24 x 108 = 2592Wh for the V13, meaning the Burn-e has 111% the battery capacity of the V13.

EZbike Canada|Level.2 Commuter Ebike Step-over

Brand Name vs No Name

 Generally, PEV manufacturers would label their battery if they used brand name cells, the big three being Samsung, LG, and Panasonic.  If it’s unlabeled, or advertised as “generic (GN)” or “Chinese (CN)”, then it may give you up to 20% less capacity and durability as brand name ones.  However, the key word is “up to”, they are usually only 10% - 15% less than brand name cells.  However, brand name batteries will always cost significantly more, many times costing double as unbranded ones.
